Autel KM100 + G-BOX2 Program 2017-2022 Toyota 8A(H) AKL

Autel MaxiIM KM100 Key Fob Programmer can support to program 2017-2022 Toyota Hilux/ Fortuner/ Innova 8A(H) all blade keys lost by OBD successfully. Follow the procedure below to learn how to do.



Accessories Required

Autel KM100

Toyota 8A Blade AKL Kit

G-BOX2/ G-BOX3

A new blade key



Connect Toyota 8A AKL Kit, G-BOX2 & KM100 to OBD interface.



Operation

IMMO >> Toyota >> Manual selection >> Other >> FORTUNER/ HILUX SW4 >> Blade key >> Yes >> Control unit >> Immobilizer >> Immobilizer(H 8A/8E) >> All keys lost (using 8A AKL cable)



Warning:

You must turn off the Bluetooth function of the device and connect VCI to KM100 with USB cable. Otherwise, the function may fail! Press “OK”.

Here we can check the detailed wiring diagram.



Insert a blade key without chip then turn ignition on.

Retrieving critical data…

Key type: SLK6, press “OK”.

The simulator is generated successfully, press “OK”.



Please turn off ignition and remove the blade key, restore the original vehicle circuit.

Remove G-BOX2 & Toyota 8A Blade Kit, connect VCI200 to OBD directly.

Press “OK”.



Please keep the antenna of device close to the ignition coil, then insert a blade key without chip into ignition slot and turn ignition on. Press “OK”.



Turn off ignition, remove the APB112 simulator key and key blade, insert the key with chip and ignition stay off state.



Please wait around 5-180 seconds until the security light is off, then key programming completes.
